second-hand PSG Series Compound Cone Crusher

Second-hand stone crusher

second-hand Compound Cone Crusher

Scan your phone once

Summary Features：

Feed size: ≤1000MM

Production Capacity: 15-850 T/H

Suitable Materials: Pebbles, Basalt, Granite, Iron Ore

Application Range: Granite, Limestone, Concrete, Quicklime, Gypsum, Slaked Lime

+86-13676907460

ONLINE INQUIRY

Product Details

Product Introduction

The PSG series compound cone crusher is widely used in metallurgical industry, construction industry, road construction industry, chemical industry and silicate industry. It is suitable for crushing various ores and rocks with medium and above medium hardness.The PSG series compound cone crusher features high crushing force, high efficiency, high processing capacity, low operating cost and convenient adjustment. It is made of high-quality materials with a rational structural design, and the crushed product has uniform particle size, reducing cyclic load. In medium and large-scale crushers, a multi-cylinder hydraulic cleaning system is adopted, which reduces downtime and lowers the operating labor intensity. Moreover, each crusher has multiple chamber types, and users can choose different chamber types according to different needs.

Technical Parameter

Technical Parameters

Specification	Model	Chamber Type	Big end of the crushing cone Diameter (mm)	Discharge opening adjustment range (mm)	Recommended minimum discharge opening feed size (mm)	Maximum feed size (mm)	Capacity (t/h)	Main motor power (kw)	Machine's own weight (kg)	Overall dimensions (mm)
2'FT	PSGB-0607	Standard Fine	600	6-38	70	60	16-50	30	4500	2195×1158×1651
2'FT	PSGB-0609	Standard Medium	600	10-38	95	80	18-65	30	4500	2195×1158×1651
2'FT	PSGB-0611	Standard Coarse	600	13-38	110	90	22-70	30	4500	2195×1158×1651
2'FT	PSGD-0603	Short Head Fine Type	600	3-13	35	30	9-35	30	4500	2195×1158×1651
2'FT	PSGD-0605	Short Head Coarse Type	600	5-16	50	40	22-70	30	4500	2195×1158×1651
3'FT	PSGB-0910	Standard Fine Type	900	9-22	102	85	45-91	75	9980	2656×1636×2241
3'FT	PSGB-0917	Standard Coarse Type	900	13-38	175	150	59-163	75	9980	2656×1636×2241
3'FT	PSGB-0918	Standard Extra-Thick Type	900	25-38	178	150	118-163	75	9980	2656×1636×2241
3'FT	PSGD-0904	Short Head Fine Type	900	3-13	41	35	27-90	75	10530	2656×1636×2241
3'FT	PSGD-0906	Short Head Medium Type	900	3-16	76	65	27-100	75	10530	2656×1636×2241
3'FT	PSGD-0907	Short Head Extra-Thick Type	900	6-19	102	85	59-129	75	10530	2656×1636×2241
4.25'FT	PSGB-1313	Standard Fine	1295	13-31	137	115	109-181	160	22460	2983×1866×3156
4.25'FT	PSGB-1321	Standard Medium	1295	16-38	210	178	132-253	160	22460	2983×1866×3156
4.25'FT	PSGB-1324	Standard Coarse	1295	19-51	241	205	172-349	160	22460	2983×1866×3156
4.25'FT	PSGB-1325	Standard Extra Coarse	1295	25-51	259	220	236-358	160	22460	2983×1866×3156
4.25'FT	PSGD-1306	Short Head Fine	1295	3-16	64	54	36-163	160	22590	2983×1866×3156
4.25'FT	PSGD-1308	Short Head Medium	1295	6-16	89	76	82-163	160	22590	2983×1866×3156
4.25'FT	PSGD-1310	Short Head Coarse	1295	8-25	105	89	109-227	160	22590	2983×1866×3156
4.25'FT	PSGD-1313	Short Head Extra Coarse	1295	16-25	133	113	209-236	160	22590	2983×1866×3156
5.5'FT	PSGB-1620	Standard Fine	1676	16-38	209	178	181-327	250	43270	3941×2954×3771
5.5'FT	PSGB-1624	Standard Medium	1676	22-51	241	205	258-417	250	43270	3941×2954×3771
5.5'FT	PSGB-1626	Standard Coarse	1676	25-64	269	228	299-635	250	43270	3941×2954×3771
5.5'FT	PSGB-1636	Standard Extra Coarse	1676	38-64	368	313	431-630	250	43270	3941×2954×3771
5.5'FT	PSGD-1607	Short Head Fine Type	1676	5-13	70	60	90-209	250	43870	3941×2954×3771
5.5'FT	PSGD-1608	Short Head Medium Type	1676	6-19	89	76	136-281	250	43870	3941×2954×3771
5.5'FT	PSGD-1613	Short Head Coarse Type	1676	10-25	133	113	190-336	250	43870	3941×2954×3771
5.5'FT	PSGD-1614	Short Head Extra Coarse Type	1676	13-25	133	113	253-336	250	43870	3941×2954×3771
7'FT	PSGB-2127	Standard Fine	2134	19-38	278	236	544-1034	400	86730	4613×3302×4638
7'FT	PSGB-2133	Standard Medium	2134	25-51	334	284	862-1424	400	86730	4613×3302×4638
7'FT	PSGB-2136	Standard Coarse	2134	31-64	369	314	1125-1814	400	86730	4613×3302×4638
7'FT	PSGB-2146	Standard Extra Coarse	2134	38-64	460	391	1252-1941	400	86730	4613×3302×4638
7'FT	PSGD-2110	Short Head Fine	2134	5-16	105	89	218-463	400	89500	4613×3302×4638
7'FT	PSGD-2113	Short Head Medium	2134	10-19	133	113	404-580	400	89500	4613×3302×4638
7'FT	PSGD-2117	Short Head Coarse	2134	13-25	178	151	517-680	400	89500	4613×3302×4638
7'FT	PSGD-2120	Short Head Extra Coarse	2134	16-25	203	172	580-744	400	89500	4613×3302×4638

Product Features

1、Multi-cylinder crushing chamber type, flexible application, strong adaptability of crushing chamber.

2、Supports large crushing ratio; key parts are made of special materials.

3、Easy to operate, reduces downtime, low power consumption, reasonable allocation.

4. Reasonable selection of parts and structural design result in long service life and low maintenance costs during daily operation.
